Magellan 330 Series User Manual

10 Magellan MAP 330 GPS Receiver
Basic Operation
Basic Operation
External Connections -
Provides connection to
external power and data
handling devices.
Power/Data Cable
(purchased
separately) - Allows
access to the external
connector for the
MAP 330. See the
section on
Accessories for
description of
available cables.
Battery Cover
Battery Cover
Screw and Wrist
Strap Ring
Tuning the MAP 330 On
Press
Start-up Screen
displayed
Warning Screen
displayed
ENTER
Press
[You have 10
seconds to press
ENTER accepting
the displayed
warning or the
MAP 330 will shut
off.]
The last navigation screen you were viewing will be displayed. If the last
navigation screen view was the Map screen, the last zoom scale setting will be
used.
Pressure Relief
Vent
