4.4. ASSEMBLY AND PRELIMINARY PREPARATION FOR SET UP
The machine is delivered partially assembled, so it is necessary to mount all those parts left not assembled for
packaging reasons.
The buyer must verify that all the machine parts are safe and not damaged after transportation, before going on
with assembling. In particular we suggest to verify the most delicate parts, as electrical or mechanical
components, pneumatic tubing or the safety protection devices of the machine itself.
After assembling, it is necessary to clean all surfaces from protective oil so that the working pieces remain clean
during working operations.
MAGGI TECHNOLOGY - BORING SYSTEM 23 - REV00 Pag. 13
CLAMP SHOULDERS
Mass = about 10 kg each
INSTRUCTION HANDBOOK
TOOL KIT
CROSSPIECE
Mass = about 14 kg
BACK STOP
Mass = about 2,5 kg
BE EXTREMELY CAREFUL IN LIFTING, MOVING, TRANSPORTING THE MACHINE
THE DEVICES USED TO LIFT-MOVE-TRANSPORT THE MACHINE MUST BE CAPABLE TO
DO THE DUTY WITH NO RISK FOR PERSONS AND THINGS
ASK OTHER OPERATORS TO HELP YOU SO TO REDUCE AT MINIMUM ANY PHYSICAL
EFFORTS IN DOING THE JOB
All the assembling operations described above can be performed using the tools
purchased together with the machine
CLAMPING DEVICES
Massa = about 3 kg each
SQUARE UNITS
Mass = about 6 kg each
EXTENSION FENCE
Mass = about 7,5 kg
TOOL KIT
