Pag. 44 MAGGI TECHNOLOGY - BORING SYSTEM 23 - REV00
TABLE UNIT
POS. CODE PART NAME
Q. TY
1 00003423 BUSHER DU17x19x15 2
2 00003455 BEARING INA AXK1730 2
3 00003456 RING INA AS 1730 4
4 00018307 SCREW TCEI M8X16 UNI-5931 6
5 00018312 SCREW VTCEI M10x60 2
6 00018521 WASHER Ø8 UNI-6592 6
7 36028102 TABLE 23 1
8 36205125 LH LABEL SQUARE 1
9 36205126 RH LABEL SQUARE 1
10 36208111 ROTATION PIN 2
