ReTransfer ID Card Printer – User Manual
22
Available Encoder Modules
Upgrade Frame Only
Approximate Encoder Location
Upgrade Magnetic/Smart
Supported Cards: MIFARE, DESFire, iClass.
The OMNIKEY® 5122 Reader Board is a dual interface PC-linked reader
that reads/writes to both a 13.56 MHz contactless smart card and
virtually any contact smart card. The dual interface feature,
implemented on a small PCB, economically supports end-user
environments where both contactless and contact smart card
technology may be in use. The reader supports contactless Smart cards
with up to 424 kbps in ISO 14443 transmission mode.
Upgrade Smart Only
Magnetic encoding is enabled by default if a Ma
Encoder Module is fitted within the Printer.
The Printer’s Firmware is able to detect the Encoder
and will make the necessary configuration changes
accordingly.
Upgrade Magnetic Only
