ReTransfer ID Card Printer – User Manual
38
due to either the cleaning card was obstructed, or a faulty eject sensor.
2055
Cleaning card not ejected. Please remove card from rear of
printer
While performing a roller cleaning cycle, and having already fed in a
roller cleaning card as far as the flipper rollers and fed it back again to
the point where the print position opto sensor was unblocked, it took
too long for the feed opto sensor to become unblocked. This probably
means that the cleaning card has become jammed, perhaps due to a
physical obstruction or because the card is slipping on the rollers.
8191 General (miscellaneous) error
While attempting to retrieve a HoloKote file from the SD card, the
printer found that an invalid parameter was supplied for selecting how
the bitmap should be rotated. This indicates a bug in the firmware.
9000 The heater is over temperature
In the firmware module which controls the heated roller temperature,
the printer detected that the heated roller temperature was above the
maximum permitted level. This is either due to a fault in the control
software, or a problem with the temperature measurement hardware.
9001 The Printhead is over temperature
In the firmware module which controls the Printhead temperature, the
printer detected that the Printhead temperature was above the
maximum permitted level. This is either due to a fault in the control
software, or a problem with the temperature measurement hardware.
9002 The heater sensor is disconnected
In the firmware module which controls the heated roller temperature,
the temperature sensor alarm was triggered and the temperatures
sensor was reporting an unusually low temperature. This is almost
always because the temperature sensor is not connected properly.
9003 The Printhead is disconnected
In the firmware module which controls the Printhead temperature, the
temperature sensor was reporting an unusually low temperature. This
is almost always because the Printhead is not connected properly.
