Magicfx ECO2JET - Page 19

MAGICFX
®
ECO2JET
®
- User and Installation Manual 19
6
WARNING
Always create a safety zone around the machine with
a radius of 0.3 meter. Make sure that the area is clear of
unauthorized persons, animals and objects. Not doing
so can result in death or serious injury.
Note that overlap of safety zones in a setup with
multiple machines is allowed, as long the air grilles are
not obstructed.
0.3 m / 1 ft
top view
6
WARNING
Always keep the output zone as shown in the image
below clear of all people, animals and objects. Not
doing so may result in death or serious injury.
Note that the zone shis accordingly when the
machine is installed in a tilted position on the stage.
2m / 6 ft
0.3 m / 1 ft
6
WARNING
A poorly mounted machine will come loose when the
machine is operated. This can lead to death, serious
injury and/or property damage. Always inspect if the
machine is mounted firmly and correctly as according
to the instructions in this manual.
