Magicfx ECO2JET - Mount on a Truss

22 MAGICFX
®
ECO2JET
®
- User and Installation Manual
3.1.2. WITH AN ECO2JET
®
BRACKET
The ECO2JET
®
can also be used on stage with an ECO2JET
®
Bracket.
More information on using the ECO2JET
®
Bracket can be found in the ECO2JET
®
Bracket accessory manual.
3.2. MOUNT ON A TRUSS
The following options are available for truss mounting:
• ECO2JET
®
Bracket (MFX1802)
• Omega Brackets (MFX1804)
• Doughty Quick Trigger Clamp (100 kg) M10 (MFX3104)
• Doughty Half Coupler (100 kg) M10 (MFX3106)
Use the Omega Brackets or the ECO2JET
®
Bracket to hang the ECO2JET
®
upside down.
The ECO2JET
®
is a heavy machine. In static situations, using only one clamp is
possible. It is however recommended to use two clamps.
6
CAUTION
Installing the ECO2JET
®
in a motion truss is not
recommended.
6
CAUTION
Keep a minimum distance of 30 cm between the
machines.
