MAGICFX
®
ECO2JET
®
- User and Installation Manual 23
3.2.1. MOUNT WITH OMEGA BRACKETS
The ECO2JET
®
can be suspended from a truss by attaching Omega Brackets with
clamps to the bottom of the machine.
1. Flip the ECO2JET
®
upside down. Be careful with the nozzle.
2. Mount clamps (MFX3104 or MFX3106) to the Omega Brackets (MFX1804) using
the provided bolts and nuts.
3. Attach the Omega Brackets to the quarter turn receptacles in the ECO2JET
®
.
