Magicfx ECO2JET - Technical Data

MAGICFX
®
ECO2JET
®
- User and Installation Manual 7
1.2. TECHNICAL DATA
Product Product Name ECO2JET
®
Product Code MFX1801
Product Type SMOKE FX
Main Dimensions Length 407 mm 16 in
Width 291 mm 11.5 in
Height 468 mm 18.4 in
Weight Empty Weight 30.5 kg 67.2 lbs
Packaged Weight 31.7 kg 69.9 lbs
Environment Minimum Temperature - 10 °C 23 °F
Maximum Temperature 50 °C 122 °F
Humidity (Relative) 20 to 90 % (non-condensing)
Electrical Voltage Input 210 - 240 VAC
Voltage Frequency 50 - 60 Hz
Heat-up Power 1.5 kW (ECO)
3.5 kW (FULL)
Idle Power * 140 W
Power Connector Neutrik
®
powerCON TRUE1 (in&out)
Controlling Control Options DMX
Menu: Test Mode
Control Protocols DMX512-A (ANSI E1.11)
RDM (ANSI E1.20)
Control Connectors Neutrik
®
5-pole male/ female XLR
Configuring Configure Options On Device
RDM
Usage Consumable(s) MAGICFX
®
ECO2JET
®
Outdoor Fluid
5L MFX3090
MAGICFX
®
ECO2JET
®
Indoor Fluid 5L
MFX3091
Consumable
Consumption
0.38 L/min 2.6 min/L
Technical data
* These values are a computed average measured over a longer period of time aer
the device has finished its initial heating.
