6. Communication
6.1. Communication with EtherNet/IP device (Scanner)
MG80-EI supports CIP (Common Industrial Protocol) service functions of the
EtherNet/IP standard.
6.1.1. Tag data link（Implicit message）
MG80-EI supports Implicit message of EtherNet/IP standard and performs cyclic
communication (Tag data link) with the scanner (EtherNet/IP PLC).
MG80-EI performs cyclic communication (tag data link) with the following instances of Class0x4.
Instance 111 Output (Scanner：PLC→Adapter：MG80-EI) 34byte
Instance 124 Input (Adapter：MG80-EI→Scanner：PLC) 202byte
Instance 111 data structure details
Type
Offset
Variable
type
Label
Remarks
byte
bit
Output
0
0
BOOL
IF1.ST2.BW_QuitChannel_A
MG80-EI will output zero. Labels in
the left field are used in previous
model MG70-EI.
1
BOOL
IF1.ST2.BW_QuitChannel_B
2
BOOL
IF1.ST2.BW_QuitChannel_R
3～7
－
－
1
0
BOOL
IF1.ST2.Encoder01Reset
1～7
－
－
2
0
BOOL
IF1.ST3.BW_QuitChannel_A
1
BOOL
IF1.ST3.BW_QuitChannel_B
2
BOOL
IF1.ST3.BW_QuitChannel_R
3～7
－
－
3
0
BOOL
IF1.ST3.Encoder01Reset
1～7
－
－
4
0
BOOL
IF1.ST4.BW_QuitChannel_A
1
BOOL
IF1.ST4.BW_QuitChannel_B
2
BOOL
IF1.ST4.BW_QuitChannel_R
3～7
－
－
5
0
BOOL
IF1.ST4.Encoder01Reset
1～7
－
－
6
0
BOOL
IF1.ST5.BW_QuitChannel_A
1
BOOL
IF1.ST5.BW_QuitChannel_B
2
BOOL
IF1.ST5.BW_QuitChannel_R
3～7
－
－
7
0
BOOL
IF1.ST5.Encoder01Reset
1～7
－
－
