61
Instance service
ID
Services
0x1
Get_Attribute_All
0xE
Get_Attribute_Single
0x4E
Forward_Close
0x52
Unconnected_Send
0x54
Forward_Open
6.2.5. CIP Class 0xF5 TCP/IP Interface object
Class attributes
ID
Access
Data Type
Description
Default
0x1
Get
UINT
Revision
4
0x2
Get
UINT
Max instance
1
0x3
Get
UINT
Number of instances
1
0x6
Get
UDINT
Maximum ID Number Class Attributes
7
0x7
Get
UDINT
Maximum ID Number Instance Attributes
8
Class service
ID
Services
0x1
Get_Attribute_All
0xE
Get_Attribute_Single
Instance attribute
ID
Access
Data Type
Description
Default
0x1
Get
DWORD
Status
0x00000002(2)
0x2
Get
DWORD
Configuration Capability
0x00000060(96)
0x3
Get
DWORD
Configuration Control
0x00000000(0)
0x4
Get
Struct of
Physical Link
020h F6h 24h 01h
0x5
Get
Struct of
Interface Configuration
IP Address:192.168.0.1
Network Mask:255.255.255.0
Gateway Address:192.168.0.254
0x6
Get
String
Host Name
0xD
Get
UINT
Encapsulation_Inactivity_Timeout
120
Instance service
ID
Services
0x1
Get_Attribute_All
0xE
Get_Attribute_Single
