6.2.6. CIP Class 0xF6 Ethernet Link object
Class attributes
ID
Access
Data Type
Description
Default
0x1
Get
UINT
Revision
4
0x2
Get
UINT
Max instance
1
0x3
Get
UINT
Number of instances
1
0x6
Get
UDINT
Maximum ID Number Class Attributes
7
0x7
Get
UDINT
Maximum ID Number Instance Attributes
11
Class service
ID
Services
0x1
Get_Attribute_All
0xE
Get_Attribute_Single
Instance attribute
ID
Access
Data Type
Description
Default
0x1
Get
UDINT
Interface Speed
100[Mbps]
0x2
Get
DWORD
Interface Flags
0x0000000F (15)
0x3
Get
Arry of USINT
Physical Address
0xB
Get
UINT
Interface Capability
0：Auto-Nego , Auto-MDIX
Instance service
ID
Services
0x1
Get_Attribute_All
0xE
Get_Attribute_Single
