Magnescale MG80-EI - 7 Appendix; Parameter List

67
7. Appendix
7.1. Parameter list
Parameter list
Item
Set value (ASCII code)
Lower limit
Upper limit
Default
Network information
IP address
0x00000000
0xFFFFFFFF
0xC0A86401
Subnet mask
0x00000000
0xFFFFFFFF
0xFFFFFF00
Default gateway
0x00000000
0xFFFFFFFF
0xC0A864FE
Reserved
-
-
-
Input
resolution
Measuring
unit １
～
Measuring
unit 16
Sign
+
Positive direction
+
-
+
-
Minus direction
Resolution
1
0.1μm
1
6
1
2
0.5μm
3
1.0μm
4
2.0μm
5
5.0μm
6
10.0μm
Reference
point
0
OFF
0
1
0
1
ON
output
Frame A
～
Frame P
Output
type
0
Current values
0
3
0
1
Maximμm values
2
Minimμm values
3
Peak to peak values
