6.1.3. CIP communication command list
The following is a CIP communication command list.
CIP communication command list
Command
number
Command
Overview
4(0x04)
Input resolution setting
[Axis number]、[Sign]、[Input resolution setting value]
5(0x05)
Input resolution acquisition
[Axis number]
6(0x06)
Reference point use setting
[Axis number]、[Reference point use setting]
7(0x07)
Reference point use setting acquisition
[Axis number]
8(0x08)
Reference point clear
[Axis number]
9(0x09)
Axis calculation setting
[Frame number]、[Sign]、[Measurement value of
measuring unit Ⓐ number]、[Sign]、
[Measurement value of measuring unit Ⓑnumber]
10(0x0A)
Axis calculation acquisition
[Frame number]
11(0x0B)
Output mode setting
[Frame number]、[Output mode setting]
12(0x0C)
Output mode acquisition
[Frame number]
13(0x0D)
Comparator group number setting
[Frame number]、[Comparator group number setting]
14(0x0E)
Comparator group number acquisition
[Frame number]
15(0x0F)
Comparator step number setting
[Frame number]、[Comparator step number mode
setting]
16(0x10)
Comparator step number acquisition
[Frame number]
17(0x11)
Comparator threshold setting
[Frame number]、[Ｇroup number]、[Step number]、
[Comparator threshold setting]
18(0x12)
Comparator threshold acquisition
[Frame number]、[Ｇroup number]、[Step number]
19(0x13)
I / O function assignment setting
[Target IO number]、[Input/output identification]、
[Terminal number]、[Input or output function setting]
20(0x14)
I / O function assignment acquisition
[Target IO number]、[Input/output identification]、
[Terminal number]
21(0x15)
Reset
[Frame number]
22(0x16)
Preset value setting
[Frame number]、[Preset value setting]
23(0x17)
Preset value acquisition
[Frame number]
24(0x18)
Preset call
[Frame number]
25(0x19)
Master preset value setting
[Axis number]、[Master preset value setting]
26(0x1A)
Master preset value acquisition
[Axis number]
27(0x1B)
Master preset call
[Axis number]
31(0x1F)
Start
[Frame number]
32(0x20)
Pause ON / OFF setting
[Frame number]、[Pause ON / OFF setting]
33(0x21)
Pause ON / OFF acquisition
[Frame number]
57(0x39)
Unit setting
[Unit setting]
58(0x3A)
Unit acquisition
－
62(0x3E)
Parameter save
－
63(0x3F)
Parameter initialization
－
