38
The following shows the details of the CIP communication command.
(1) Input resolution setting command
Offset
Label
Setting value (Hex)
0
INC
Enter an arbitrary value different from the value previously sent.
1
CMD
0x04
2
RSV1
0x00
3
RSV2
0x00
4
DATA1
※ASCII code
Axis number
Setting value (Hex)
‘1’～’10’
0x30～0x39
‘11’～’16’
0x41～0x46
5
DATA2
※ASCII code
Sign
Setting value (Hex)
‘＋’
0x2B
‘－’
0x2D
6
DATA3
※ASCII code
Input resolution
Setting value (Hex)
‘1’：0.1μm
0x31
‘2’：0.5μm
0x32
‘3’：1.0μm
0x33
‘4’：2.0μm
0x34
‘5’：5.0μm
0x35
‘6’：10.0μm
0x36
7～15
DATA4
～
DATA11
Dummy
0x00
