6.2. CIP object
The CIP (Common Industrial Protocol) object specifications of EtherNet/IP
supported by MG80-EI are listed below.
6.2.1. Supported CIP object
CIP ID
Name
0x01
Identity object
0x04
Assembly object
0x06
Connection manager object
0xF5
TCP/IP interface object
0xF6
Ethernet link object
0x64
Vendor Specific Class（Bus controller）
0x65
Vendor Specific Class（I/O module）
6.2.2. CIP Class 0x01 Identity object
Class attributes
ID
Access
Data Type
Description
Default
0x1
Get
UINT
Revision
1
0x2
Get
UINT
Max instance
1
0x3
Get
UINT
Number of instances
1
0x6
Get
UDINT
Maximum ID Number Class Attributes
7
0x7
Get
UDINT
Maximum ID Number Instance Attributes
8
Class service
ID
Servicess
0x1
Get_Attributes_All
0xE
Get_Attribute_Single
