Magnescale MG80-EI - Page 32

31
93
0～3
－
－
MG80-EI will output zero. Labels in the
left field are used in previous model
MG70-EI.
4
BOOL
IF1.ST10.DigitalInput01
5
BOOL
IF1.ST10.DigitalInput02
6～7
－
－
94
0
BOOL
IF1.ST11.PowerSupply01
MG80-EI will output zero. Labels in the
left field are used in previous model
MG70-EI.
1
BOOL
IF1.ST11.PowerSupply02
2～7
－
－
95
0
BOOL
IF1.ST11.BW_Channel_A
A signal of axis 10
1
BOOL
IF1.ST11.BW_Channel_B
B signal of axis 10
2
BOOL
IF1.ST11.BW_Channel_R
Z signal of axis 10
3～7
－
－
Unused Outputs zero
96
0～3
－
－
MG80-EI will output zero. Labels in the
left field are used in previous model
MG70-EI.
4
BOOL
IF1.ST11.DigitalInput01
5
BOOL
IF1.ST11.DigitalInput02
6～7
－
－
97
0
BOOL
IF1.ST12.PowerSupply01
MG80-EI will output zero. Labels in the
left field are used in previous model
MG70-EI.
1
BOOL
IF1.ST12.PowerSupply02
2～7
－
－
98
0
BOOL
IF1.ST12.BW_Channel_A
A signal of axis 11
1
BOOL
IF1.ST12.BW_Channel_B
B signal of axis 11
2
BOOL
IF1.ST12.BW_Channel_R
Z signal of axis 11
3～7
－
－
Unused Outputs zero
99
0～3
－
－
MG80-EI will output zero. Labels in the
left field are used in previous model
MG70-EI.
4
BOOL
IF1.ST12.DigitalInput01
5
BOOL
IF1.ST12.DigitalInput02
6～7
－
－
100
0
BOOL
IF1.ST13.PowerSupply01
MG80-EI will output zero. Labels in the
left field are used in previous model
MG70-EI.
1
BOOL
IF1.ST13.PowerSupply02
2～7
－
－
101
0
BOOL
IF1.ST13.BW_Channel_A
A signal of axis 12
1
BOOL
IF1.ST13.BW_Channel_B
B signal of axis 12
2
BOOL
IF1.ST13.BW_Channel_R
Z signal of axis 12
3～7
－
－
Unused Outputs zero
102
0～3
－
－
MG80-EI will output zero. Labels in the
left field are used in previous model
MG70-EI.
4
BOOL
IF1.ST13.DigitalInput01
5
BOOL
IF1.ST13.DigitalInput02
6～7
－
－
103
0
BOOL
IF1.ST14.PowerSupply01
MG80-EI will output zero. Labels in the
left field are used in previous model
MG70-EI.
1
BOOL
IF1.ST14.PowerSupply02
2～7
－
－
