40
(4) Reference point use acquisition command
Offset
Label
Setting value (Hex)
0
INC
Enter an arbitrary value different from the value previously sent.
1
CMD
0x07
2
RSV1
0x00
3
RSV2
0x00
4
DATA1
※ASCII code
Axis number
Setting value (Hex)
‘1’～’10’
0x30～0x39
‘11’～’16’
0x41～0x46
5～15
DATA2
～
DATA11
Dummy
0x00
(5) Reference position clear command
Offset
Label
Setting value (Hex)
0
INC
Enter an arbitrary value different from the value previously sent.
1
CMD
0x08
2
RSV1
0x00
3
RSV2
0x00
4
DATA1
Axis number※ASCII code
Axis number
Setting value (Hex)
‘1’～’10’
0x30～0x39
‘11’～’16’
0x41～0x46
5～15
DATA2
～
DATA11
Dummy
0x00
