(7) Axis calculation acquisition command
Offset
Label
Setting value (Hex)
0
INC
Enter an arbitrary value different from the value previously sent.
1
CMD
0x0A
2
RSV1
0x00
3
RSV2
0x00
4
DATA1
※Code
Frame number
Setting value (Hex)
‘A’～’J’
0x30～0x39
‘K’～’P’
0x41～0x46
5～15
DATA2
～
DATA11
Dummy
0x00
(8) Output Mode setting command
Offset
Label
Setting value (Hex)
0
INC
Enter an arbitrary value different from the value previously sent.
1
CMD
0x0B
2
RSV1
0x00
3
RSV2
0x00
4
DATA1
※Code
Frame number
Setting value (Hex)
‘A’～’J’
0x30～0x39
‘K’～’P’
0x41～0x46
5
DATA2
※ASCII code
Output Mode
Setting value (Hex)
‘0’：Current values
0x30
‘1’：Maximum values
0x31
‘2’：Minimum values
0x32
‘3’：Peak to peak values
0x33
The output data of the MG70-EI are number of pulses collected from
the measuring unit. Calculation is needed in the program to convert
those into measurement values.
measurement values = number of pulses × sensor resolution
Output data of the MG80-EI is measurement value in 0.1μm unit.
It is necessary to remove the calculation program when replacing
MG70-EI to MG80-EI.
6～15
DATA3
～
DATA11
Dummy
0x00
