(11) Comparator group number acquisition command
Offset
Label
Setting value (Hex)
0
INC
Enter an arbitrary value different from the value previously sent.
1
CMD
0x0E
2
RSV1
0x00
3
RSV2
0x00
4
DATA1
※Code
Frame number
Setting value (Hex)
‘A’～’J’
0x30～0x39
‘K’～’P’
0x41～0x46
5～15
DATA2
～
DATA11
Dummy
0x00
(12) Comparator step number setting command
Offset
Label
Setting value (Hex)
0
INC
Enter an arbitrary value different from the value previously sent.
1
CMD
0x0F
2
RSV1
0x00
3
RSV2
0x00
4
DATA1
※Code
Frame number
Setting value (Hex)
‘A’～’J’
0x30～0x39
‘K’～’P’
0x41～0x46
5
DATA2
※Code
Comparator step number mode number
Setting value (Hex)
‘0’：0 steps
0x30
‘2’：2 steps
0x32
‘4’：4 steps
0x34
6～15
DATA3
～
DATA11
Dummy
0x00
