(22) Master preset value setting command
Offset
Label
Setting value (Hex)
0
INC
Enter an arbitrary value different from the value previously sent.
1
CMD
0x19
2
RSV1
0x00
3
RSV2
0x00
4
DATA1
※ASCII code
Axis number
Setting value (Hex)
‘1’～’10’
0x30～0x39
‘11’～’16’
0x41～0x46
5
～
8
DATA2
～
DATA5
Master preset value
※4 Byte 8 digit integer (Hex)
(Example)
＋0.1μm → ＋1 (0x01)
－0.1μm → －1 (0xFFFFFFFF)
＋12.3456mm → ＋123456 (0x19C53)
－12.3456mm → －123456 (0xFFFE1DC0)
11～15
DATA6
～
DATA11
Dummy
0x00
(23) Master preset value acquisition command
Offset
Label
Setting value (Hex)
0
INC
Enter an arbitrary value different from the value previously sent.
1
CMD
0x1A
2
RSV1
0x00
3
RSV2
0x00
4
DATA1
※ASCII code
Axis number
Setting value (Hex)
‘1’～’10’
0x30～0x39
‘11’～’16’
0x41～0x46
5～15
DATA2
～
DATA11
Dummy
0x00
