Magnescale MG80-EI - Page 70

69
Item
Set value(ASCII code)
Lower limit
Upper limit
Default
Comparator
setting
Flame A
～
Flame P
Comparator
group
number
1
Group 1
1
8
1
2
Group 2
3
Group 3
4
Group 4
5
Group 5
6
Group 6
7
Group 7
8
Group 8
Mode
0
None
0
2
0
1
Step 2
2
Step 4
Comparator
thresholds
for groups
1 to 8
Step 1
Compare threshold1
-99999999
99999999
0
Step 2
Compare threshold2
Step 3
Compare threshold3
Step 4
Compare threshold4
I/O
IO1～IO2
Input
function for
each bit
Bit 0～7
0
Target ID(bit0)
0
X
X
1
Target ID(bit1)
2
Target ID(bit2)
3
Target ID(bit3)
4
Data request signal
5
Comparator group
(bit0)
6
Comparator group
(bit1)
7
Comparator group
(bit2)
8
Reset command
9
Preset call command
A
Reference point
reacquisition
B
Output value mode
(bit0)
C
Output value mode
(bit1)
D
Start signal
E
Pause signal
X
None
Output
function
Bit 0～7
0
Data ready signal
0
7
X
1
Comparator area 0
2
Comparator area 1
3
Comparator area 2
4
Comparator area 3
5
Comparator area 4
6
Alarm output
7
Reference point
pass flag
X
None
