C. A/B Pushbutton Select Functions (Standard)
Type-A selector sequence : A+B → A → B → A+B …
Type-B selector sequence : Off → A → B → Off → A → B …
Type-C selector sequence : A → B → A+B → A → B → A+B …
Type-D selector sequence : Off → A → B → A+B → Off → A → B → A+B …
NO Dip Set PB1 PB2 PB3 PB4 PB5 PB6 PB7 PB8 PB9 PB10 PB11 PB12
029
00011101
A/1.2
030
00011110
B/1.2
031
00011111
C/1.2
032
00100000
D/1.2
033
00100001
A/3.4
034
00100010
B/3.4
035
00100011
C/3.4
036
00100100
D/3.4
037
00100101
A/1.2 A/3.4
038
00100110
A/1.2 B/3.4
039
00100111
A/1.2 C/3.4
040
00101000
A/1.2 D/3.4
041
00101001
B/1.2 B/3.4
042
00101010
B/1.2 C/3.4
043
00101011
B/1.2 D/3.4
044
00101100
C/1.2 C/3.4
045
00101101
C/1.2 D/3.4
046
00101110
D/1.2 D/3.4
047
00101111
A/1.2
048
00110000
B/1.2
049
00110001
C/1.2
050
00110010
D/1.2
