Installation and assembly
1. Drill the boreholes for the sleeves with inner thread according to the foun-
dation plan.
NOTICE
Wrong orientation of the pedestrian gate! The pedestrian gate is not sym-
metrically constructed. Align the pedestrian gate so that the passage side
is on the correct side. Observe foundation plan.
2. Clean the boreholes with compressed air.
3. Inject composite mortar into the boreholes.
4. Turn in the sleeves with inner thread to the bottom of the boreholes by
hand. The BSS100 attachment set contains mounting aids.
5. Wait for the curing time. Follow separate instructions.
6. Place pedestrian gate.
7. Place sleeve with inner thread, washers and hexagon head screws.
WARNING
Possible injuries due to falling pedestrian gate!
Use screws M8 x 30 from attachment set BSS100. Do not use the M8 x 16
screws.
8. Slightly tighten the screws.
9. Align the pedestrian gate.
10. Tighten the screws firmly.
11. If necessary, seal the housing with a silicone joint.
12. Arrange electrical connections. ä Page 59, chapter 8.
13. Mount strips, side parts, and cover. ä Page 53, chapter 7.8.
