Magnetic MHTM FlowMotion mWing - Page 46

46
mWing
Installation and assembly
1
2
3
4
7
6
5
Mag10010
Fig. 16: Mounting and preparing the base plate
1 Foundation / raw floor
2 Planned finished floor
3 Drilling template
4 Nut M8, slightly above the planned finished floor
5 Threaded rods M8 x 210, stainless steel
6 Nut M8
7 Base plate
