Magnetic MHTM FlowMotion mWing - Page 52

52
mWing
Installation and assembly
Mag10027
8x
1
2
3
Fig. 22: Mounting version "gluing plate mounting" – Mounting the pedestrian gate
1 Screw M8 x 16, stainless steel, (8 x)
2 Washer A 8.4 mm, stainless steel (4 x)
3 Base plate
