BE 57-660 Eclipse Model 700 Guided Wave Radar Transmitter
2
.6.5 Model 700 Configuration Menu — Device Setup
H
ome Screen
M
ain Menu
D
evice Setup
Q
uick Start
Identity
B
asic Config
I
/O Config
Display Config
Advanced Config
F
actory Config
S
ensitivity:
0
to 100 echo strength units
Blocking Distance:
-2 m to 30 m
(
-7.5 to +100 feet)
S
afety Zone Alarm:
None
3.6 mA
22 mA
L
atched 3.6 mA
L
atched 22 mA
Safety Zone Height:
(not used when Safety Alarm is
None)
5
cm to 30 m
(2 inches to 100 feet)
Reset SZ Alarm
(used when Safety Alarm is Latch
3.6 mA or Latch 22 mA)
Failure Alarm Delay:
0 to 5 seconds
Level Trim:
-0.6 m to + 0.6 m
(-2.00 to + 2.00 feet)
THRESHOLD SETTINGS
Lvl Thresh Mode:
Auto Largest
(not used with Interface and Level)
Fixed Value
Auto Upper
Sloped
Lvl Thresh Value:
0 to 100 echo strength units
Sloped Start Value
(used when Lvl Thresh Mode is
Sloped)
0 to 100 echo strength units
Sloped Start Value:
(used when Lvl Thresh Mode is
Sloped)
Sloped Start Distance:
(used when Lvl Thresh Mode is
Sloped)
Sloped End Dist:
(used when Lvl Thresh Mode is
Sloped)
7 to 30 m
(25 to 100 feet)
A
uto Upper Limit:
(used when Lvl Thresh Mode is Auto
U
pper)
Ifc Lvl Thresh Mode:
(
Interface and Level only)
A
uto Largest
F
ixed Value
Ifc Lvl Thresh Value:
(Interface and Level only)
0
to 100 echo strength units
EoP Thresh Mode:
Auto Largest
F
ixed Value
E
oP Thresh Value:
0 to 100 echo strength units
ENDofPROBE ANALYSIS:
EoP Polarity:
Positive
Negative
EoP Analysis:
(not used with Interface and Level)
Off
On
EoP Dielectric:
(not used with Interface and Level)
1.20 to 9.99
ECHO REJECTION:
View Echo Curve
REJECTION CONTROL:
Reject Curve State:
Off
Disabled
[Enabled]
Reject Curve Mode:
Level
Distance
Saved Medium
NEW REJECT CURVE:
Actual Medium
Save Reject Curve
Compensation:
None
Auto
Manual
Vapor Dielectric
1.00 to 2.00
M
ax. Level Jump
Buildup Detection:
Off
On
A
NALOG OUTPUT:
H
ART Poll Address:
0 to 63
Analog Output Mode:
D
isabled (Fixed)
E
nabled (PV)
[Fixed Current Value]
4 to 20 mA
A
DJUST ANALOG OUTPUT:
A
djust 4mA
Adjust 20mA
New User Password:
0 to 59,999
CONFIG CHANGED:
Indicator Mode:
Disabled
Enabled
Reset Config Chngd:
Reset?
No
Yes
Reset Parameters:
No
Yes
LEVEL TABLE SETUP:
Level Table Mode:
Disabled
Enabled
