BE 57-660 Eclipse Model 700 Guided Wave Radar Transmitter
2
.7.4 HART Menu – Model 700
1 PV
2
PV Loop Current
3
PV % Range
4 Device Setup
5 Setup Wizard
6 Diagnostics
7 Measured Values
1 Present Status
2 Event History
3 Advanced
Diagnostics
4 Echo Curves
5 Echo History
6 Trend Data
1 Echo Graph
2 Curve 1
3 Curve 2
4 Refresh Graph
5 Zoom
6
Save Ref Echo Curve
7 New Rejection Curve
8 Parameters
1 Echo Graph
2 Curve 1
3 Curve 2
4 Refresh Graph
5 Zoom
6 Echo History Log
7 Refresh History
8 History Setup
9 Delete History
10 Set Clock
1 Enter Password
2
Dielectric Range
3 Sensitivity
4 Blocking Distance
5 Lvl Thresh Mode
6 Sloped Start Value
7 Lvl Thresh Value
8 Sloped End Distance
9 Ifc Lvl Thresh Value
10 EoP Thresh Value
1 Echo History Mode
2 Trigger Events
3 Time Triggers
4 Set Clock
5 Enter Password
1 Trend Data
2 Level
3 Ifc Level
4 Upr Thickness
5 Volume
6 Flow
7 Loop
8 Range
9 Analog Output
10 % Output
11 Echo Strength
12 Ifc Echo Strength
13 Data Log Setup
1 Trending Variables
2 Time Setup
3 Set Clock
4 Enter Password
