BE 57-660 Eclipse Model 700 Guided Wave Radar Transmitter
3
.7.2 Small Coaxial Probe
continued
20A1
13 14 15 | INSERTION
LENGTH
X X X
cm (030 – 610)
inches (012 – 240)
unit of measure deter-
mined by 2nd digit of
model number
7 | FLANGE OPTIONS — Offset flanges are available only with small
coaxial probes
0 None
1 Offset (For use with AURORA) — 4" flange only
2 Offset with 1/2" NPT Vent (For use with AURORA) — 4" flange only
3 Offset with 3/4" NPT Vent (For use with AURORA) — 4" flange only
6
| CONSTRUCTION CODES
0 Industrial
8 | MATERIAL OF CONSTRUCTION -
FLANGE/NUT/ROD/INSULATION
A 316 SS/316L SS
9 | SPACER MATERIAL
1
TFE (+200 °C/+400 °F) — ε
r
≥ 1.4
12 | SPECIAL OPTIONS
0
Single Length Probe
(Non-Segmented)
10 | O-RING MATERIALS/SEAL OPTIONS
0 Viton
®
GFLT — Available only with 3rd digit T
2 Kalrez
®
4079 — Available only with 3rd digit T
8 Aegis PF 128 (NACE) — Available only with 3rd digit T
A Kalrez 6375 — Available only with 3rd digit T
N
None — glass ceramic alloy — Available only with
3rd digit P
7 0
12 3 456 7 8910 11 12 13 14 15
11 | PROBE SIZE/ELEMENT TYPE/
FLUSHING CONNECTION
2 Small Coaxial (22 mm/0.875 inches)
To Next Page
