.7.4 Single Rigid Rod Probe
continued
6 | CONSTRUCTION CODES
7 | FLANGE OPTIONS
0 Industrial
0 None
12 | SPECIAL OPTIONS
0
Non-Removable Rod
Available only with PFA Coated
Probes(8th digit F or P)
1
Removable Rod
Not available with PFA Coated
Probes(8th Digit F or P)
11 | PROBE SIZE/ELEMENT TYPE/
FLUSHING CONNECTION
0 Standard Single Rod
8 | MATERIAL OF CONSTRUCTION - MFG/NUT/ROD/INSULATION
A 3
16 SS/316L SS
F F
aced Flange, PFA coated wetted surfaces
P P
FA coated rod
9 | SPACER MATERIAL
0 None
10 | O-RING MATERIALS/SEAL OPTIONS
0 Viton
®
GFLT
2 Kalrez 4079
8 Aegis PF 128 (NACE)
A Kalrez 6375
7 00 0 0
12 3 456 7 8910 11 12 13 14 15
13 14 15 | INSERTION
LENGTH
X X X
cm (030 – 732)
inches (012 – 288)
maximum 610 cm
when 8th digit = F or P
unit of measure deter-
mined by 2nd digit of
model number
