Careful selection of probe design and materials for a specific
application will minimize media buildup on the probe.
See Section 3.3.3 of Installation and Operating Manual
57-600 for more detailed application information and
limitations.
5.1.2 Environmental
See Sect. 3.6.1 of Installation and Operating Manual
57-600 for Environmental limitations.
5.2 Skill Level of Personnel
Personnel following the procedures of this safety manual
should have technical expertise equal to or greater than that
of a qualified Instrument Technician.
5.3 Necessary Tools
Following are the necessary tools needed to carry out the
prescribed procedures:
• Open-wrenches or adjustable wrench to fit the process con-
nection size and type.
••
Coaxial probe 1
1
⁄2" (38mm)
••
Twin Rod probe 1
7
⁄8" (47mm)
••
Transmitter 1
1
⁄2" (38mm)
••
Torque wrench is highly desirable
• Flat-blade screwdriver
• Cable cutter and 3/32” (2.5mm) hex wrench (7X1, 7X2,
7X5 and 7X7 Flexible probes only)
• Digital multimeters or digital volt/ammeter
• 24 VDC power supply, 23 mA minimum
5.4 Storage
The device should be stored in its original shipping box
and not be subjected to temperatures outside the storage
temperature (-50° C to +80° C) shown in the ECLIPSE
Enhanced Model 705 Installation and Operating Manual
and associated specifications.
5.5 Installation
Refer to the ECLIPSE Enhanced Model 705 Installation
and Operating Manual Bulletin 57-600 manual for the
proper installation instructions.
6
57-650 Eclipse
®
SIL Functional Safety Manual
