26
57-600 Eclipse
®
Guided Wave Radar Transmitter
2.6.5.2 Measurement Type: Level and Volume (Loop Control = Volume)
Display Action Comment
44
Fid Gain
xxx
Superuser Password
45
Window
xxx
Factory Parameter
46
Conv Fct
xxxx
Factory Parameter Calibration parameter
47
Scl Ofst
xxx
F
actory Parameter
C
alibration parameter
48
Neg Ampl
xxx
Superuser Password Diagnostic factory setting
49
Pos Ampl
xxx
Superuser Password Diagnostic factory setting
50
Signal
xxx
Diagnostic Display Indication of level signal amplitude
51
Compsate
(select)
Superuser Parameter Select from None, Manual, Auto
52
7xKCorr
xxx
Superuser Parameter Distance in mm from fiducial to user reference point
(7xK probe characteristic)
53
ElecTemp
xxx C
Diagnostic Display Present temperature in electronics compartment
(degrees Celsius)
54
Max Temp
xxx C
Diagnostic Display Maximum electronics temperature recorded
55
Min Temp
xxx C
Diagnostic Display Minimum electronics temperature recorded
56
SZ Hyst
xx.x lu
Diagnostic Display Diagnostic factory setting
