56
57-600 Eclipse
®
Guided Wave Radar Transmitter
Temperature/Pressure Charts
3.6.6 Physical
inches (mm)
33.00 or 144
(838 or 3650)
3.75
(95)
3.00
(76)
2.75
(70)
2.00
(51)
3.50
(89)
2 Holes
.38 (10) Dia.
4.00
(102)
4.12
(105)
3.28
(83)
Elect.
Conn.
Qty. 2
45
4.00
(102)
Eclipse
®
Remote Configuration
4.38
(111)
8.43
(214)
4.94
(126)
45 View
Eclipse
®
Housing
(45° View)
7XB, 7XF, 7X7
0
2
0
40
60
80
1
00
120
140
160
1
00 150 200
250
Ambient Temperature (°F)
3
00
Process Temperature (°F)
Ambient Temperature vs Process Temperature
3
50
400
1
80
2
00
0
100
2
00
3
00
4
00
500
6
00
7
00
800
900
1000
1100
1200
-40
Process Pressure (psig)
0 100 200 300 400
Process Temperature (°F) (max. 400)
7X1, 7X7, 7XA, 7XB, 7XF
7XG, 7XM, 7XN, 7XR, 7XT
7XF-F
0
1000
1500
2000
3000
3500
4500
5000
5
500
6000
6500
0 200 500 700
Process Pressure (psig)
7XD, 7XL HTHP (max. +800 °F)
100 300-200-320 -100 400 600 800
4000
2500
500
7XS (max. +575 °F)
7XJ (max. +605 °F)
7XQ (max. +650 °F)
Process Temperature (°F)
