3.7.2 Probe
61
7
57-600 Eclipse
®
Guided Wave Radar Transmitter
Refer to pages 59 and 60 for selections
0 Viton
®
GFLT
1 EPDM (Ethylene Propylene Rubber)
2 Kalrez
®
4079
8 Aegis PF128
N None (Use with probes 7xD, 7xP, 7xF-E, 7xF-F, 7xF-G)
7
E ECLIPSE GWR probe, English unit of measure
7M ECLIPSE GWR probe, Metric unit of measure
PROCESS CONNECTION SIZE/TYPE
Refer to page 63 for selections
LENGTH
B
ASIC MODEL NUMBER
O-RINGS
CONFIGURATION/STYLE
MATERIAL OF CONSTRUCTION
A 316/316L stainless steel
B Hastelloy C, Configuration/Style codes A, B, D, F, G, J, P, R and T only
C Monel, Configuration/Style codes A, B, D, F, G, J, P, R and T only
E
Hygienic, 316/316L stainless steel (20 R
a
finish), Configuration/Style code F only,
Process connections codes 2P, 3P, 4P, 5P, 6P, and 9P only
F
PFA faced flange, 2" to 4", 150# to 300#, Configuration/Style code F only,
Process connection codes 43, 44, 53, 54, 63, 64, DA, DB, EA, EB, FA, and FB only
G
Hygienic, AL6XN stainless steel (20 Ra finish), Configuration/Style code F only,
Process connections codes 2P, 3P, 4P, 5P, 6P, and 9P only
H
Hygienic, Hastelloy C22, Configuration/Style code F only,
Process connections codes 2P, 3P, 4P, 5P, 6P, and 9P only
J 316/316L SST NACE Construction
K 316/316L stainless steel probe and process connection, ASME B31.1 specifications (model 7xS only)
N Enlarged coaxial probe, 316/316L stainless steel probe, 2" minimum process connection
P Enlarged coaxial probe, Hastelloy C, 2" minimum process connection
R Enlarged coaxial probe, Monel probe, 2" minimum process connection
V Optional PEEK
™
spacers (for Model 7xD probe only)
W Optional Teflon
®
spacers (for Model 7xD probe only)
4 PFA insulated rod, 2" NPT process connection or larger, Configuration/Style code F only
D Coaxial High Temp./High Pressure
3
⁄4"
process connection
or larger
Dielectric range ≥1.4
R Coaxial Overfill Probe
L Coaxial High Temp./High Pressure w/Flushing Conn.
M Coaxial Overfill Probe w/Flushing Conn.
N Coaxial Interface Probe w/Flushing Conn.
Q Coaxial Hot Water/Steam
2" process connection or larger
Dielectric range ≥10
S Coaxial Hot Water/Steam
3
⁄4"
process connection
or larger
T Coaxial Interface Dielectric range ≥1.4
B Twin Rod Standard
2" process connection
or larger
(hygienic
3
⁄4" or larger)
Dielectric range ≥1.9
7 Twin Rod Flexible
5 Twin Rod Flexible Bulk Solid
F Single Rod Standard
G Caged Overfill 2", 3" or 4"
J Single Rod High Temp./High Pressure Flexible Bulk Solid
1 Single Rod Flexible
2 Single Rod Flexible Bulk Solid Dielectric range ≥4.0
To Next Page
