Magnetrol eclipse 705 - Model 705 Configuration Data Sheet

Copy blank page and store calibration data for future reference and troubleshooting.
Item Value Value Value
Vessel Name
Vessel #
Process Medium
Tag #
Electronics Serial # TROUBLESHOOTING
Probe Serial # Working Value Non-Working Value
Level
Volume (optional)
Interface (optional)
Interface Volume (opt.)
Probe Model
Probe Mount
Measurement Type
Level Units
Probe Length
Level Offset
Volume Units (opt.)
Strapping Table (opt.)
Dielectric
Sensitivity
Loop Control
4mA point
20mA point
Damping
Blocking Distance
Safety Zone Fault
Safety Zone Height
Safety Zone Alarm
Fault Choice
Threshold
Interface Threshold
HART Poll Address
Level Trim
Trim 4mA
Trim 20mA
Level Ticks
Interface Ticks (opt.)
<Software Version>
HF cable
57-600 Eclipse
®
Guided Wave Radar Transmitter
66
705 Eclipse
®
Guided Wave Radar Transmitter
Configuration Data Sheet
