Magnetrol eclipse 705 - Performance (Model 705 Interface); Process Conditions

54
57-600 Eclipse
®
Guided Wave Radar Transmitter
Reference Conditions Reflection from liquid of selected dielectric at +70 °F (+20 °C) with 72" probe
Linearity <0.5 inch
Measured Error Upper layer ±1 inch
Interface layer ±1 inch (clean distinct interface required)
Upper Layer Dielectric 1.4–5.0
Interface Layer Dielectric >15
Resolution ±0.1 inch
Repeatability <0.5 inch
Hysteresis <0.5 inch
Response Time <1 second
Warm-up Time <5 seconds
Operating Temp. Range -40° to +175° F (-40 to +80 °C)
LCD Temp. Range -5° to +160° F (-20 to +70 °C)
Ambient Temp. Effect Approximately ±0.02% of probe length/ °C
Humidity 0-99%, non-condensing
Electromagnetic Compatibility Meets CE requirements: EN 61326
3.6.3 Performance - Model 705 Interface
Model
Coaxial
(7xA, 7xG, 7xT, 7xR)
Twin Rod
(7xB)
HTHP Coaxial
(7xD)
HP Coaxial
(7xP)
Steam ➀
(7xQ, 7xS)
Maximum
Process Temperature
7xA:
+300 °F @ 400 psig
(+150 °C @ 27 bar)
7xG, 7xT & 7xR:
+400 °F @ 270 psig
(+200 °C @ 18 bar)
+400 °F @ 275 psig
(+200 °C @ 19 bar)
+800 °F @ 1500 psig
(+427 °C @ 103 bar)
+400 °F @ 5500 psig
(+200 °C @ 380 bar)
7xQ:
+650 °F @ 2400 psig
(+340 °C @ 165 bar)
7xS:
+575 °F @ 1275 psig
(+300 °C @ 88 bar)
Maximum
Process Pressure
1000 psig @ +70 °F
(70 bar @ +20 °C)
1000 psig @ +70 °F
(70 bar @ +20 °C)
6250 psig @ +70 °F
(430 bar @ +20 °C)
6250 psig @ +70 °F
(430 bar @ +20 °C)
3000 psig @ +100 °F
(207 bar @ +38 °C)
Maximum Viscosity
500 cp (Standard)
1500 cp (Enlarged)
10,000 Caged Coaxial
1500 cp
500 cp (Standard)
1500 cp (Enlarged)
500 cp (Standard)
1500 cp (Enlarged)
500 cp
Dielectric Range
≥1.4 ≥1.9 ≥1.4 ≥1.4 >10
Hermeticity
N/A N/A
Helium leak rate <10
-8
cc/sec
@ 1 atmosphere vacuum
N/A
Model
Rigid
(7xF)
Rigid
(7xJ)
Flexible
(7x1)
Flexible
(7x2, 7x5)
Hygienic
(7xF-E)
Paint
(7xF-P)
Maximum
Process Temperature
+300 °F @ 400 psig
(+150 °C @ 27 bar)
+605 °F @ 1600 psig
(+320 °C @ 110 bar)
+300 °F @ 400 psig
(+150 °C @ 27 bar)
+150 °F @ 50 psig
(+66 °C @ 3.4 bar)
+300 °F @ 75 psig
(+150 °C @ 27 bar)
160 °F
(71 °C)
Maximum
Process Pressure
1000 psig @ +70 °F
(70 bar @ +20 °C)
3550 psig @ +70 °F
(245 bar @ +20 °C)
N/A 75 psig @ +300° F Atmospheric
Maximum Viscosity
10,000
(consult factory if severe agitation/turbulence)
2000
Dielectric Range
≥1.9
Hermeticity
N/A
3.6.4 Process Conditions
➀ Not for direct insertion into boilers.
