3.7 Model Numbers
3
.7.1 Transmitter
60
57-600 Eclipse
®
Guided Wave Radar Transmitter
0
3
⁄4" NPT
1 M20
1 Cast aluminum, dual compartment, 45° angle
2 316 stainless steel, dual compartment, 45° angle ➁
7 Cast aluminum, dual compartment, 45° angle, 12-ft remote
8
316 SS, dual compartment, 45° angle, 12-ft remote ➁
0 No digital display and keypad
A Digital display and keypad
5 24 VDC, Two-wire
BASIC MODEL NUMBER
POWER
ACCESSORIES
CONDUIT CONNECTION
MOUNTING/CLASSIFICATION
HOUSING
705 ECLIPSE Guided Wave Radar Level Transmitter
1
Integral, General Purpose & Intrinsically Safe
(FM & CSA), Non-incendive (Class I, Div. 2)
2
Remote, General Purpose & Intrinsically Safe
(FM & CSA), Non-incendive (Class I, Div. 2)
3 Integral, Explosion Proof (FM & CSA) & Non-incendive
4 Remote, Explosion Proof (FM & CSA) & Non-incendive
A
Integral, General Purpose & Intrinsically Safe
(ATEX & JIS EEx ia IIC T4)
B
Remote, General Purpose & Intrinsically Safe
(ATEX & JIS EEx ia IIC T4)
C
Integral, Explosion Proof (ATEX EEx d [ia] IIC T6)
(must be ordered with Conduit Connection Codes 0 and 1)
D
Remote, Explosion Proof (ATEX EEx d [ia] IIC T6)
(must be ordered with Conduit Connection Codes 0 and 1)
E Integral, Non-incendive (ATEX EEx n II T4..6)
F Remote, Non-incendive (ATEX EEx n II T4..6)
SIGNAL OUTPUT AND ELECTRONICS
1 0 4–20 mA with HART – SIL 1 standard electronics (SFF of 85.4%)
1 A 4–20 mA with HART – SIL 2 enhanced electronics (SFF of 91%) – Certified ➀
2 0 FOUNDATION fieldbus
™
Communication
3 0 PROFIBUS PA
™
Communication
705 5
➀ Not available with Model 7xQ steam probe.
➁ To reduce the possibility of probe damage due to vibration, it
is recommended to use a remote mount transmitter
(Mounting/Classification codes 2, 4, B, C or F) when ordering
the heavier 316 SS version.
