59
57-600 Eclipse
®
Guided Wave Radar Transmitter
3.6.6 Physical – Single Rod Probes
inches (mm)
Eclipse
®
with 7xF-E Probe
Hygienic Connection
Probe
Insertion
Length
Sanitary
Conn.
Ø 0.50" (12) Rod
2.36
(
60)
Eclipse
®
with 7xF-F Probe
Faced-Flange Connection
P
robe
Insertion
Length
2.36
(60)
Ø 0.50" (12) Rod
0.625" (16) O.D. PFA
Eclipse
®
with 7x1 Flexible Probe
Flanged or NPT Connection
2.36
(60)
Probe
Insertion
Length
Mounting
Flange
0.75" (19)
Ø 0.50" (12) Hole
TFE Weight
2.25"
(57)
1"
(25)
3.88
(99)
TFE Weight
1 lb. (454 grams)
Ø 2.0" (50)
2.24
(57)
NPT Process
Connection
7X1
12.00
(305)
7X2
3.00
(76)
Ø 0.1875" (5) Cable
Eclipse
®
with 7x2 Bulk Solids Flexible Probe
Flanged or NPT Connection
3.25
(83)
Probe
Insertion
Length
Mounting
Flange
316SS Weight
6.00
(152)
316SS Weight
5 lb. (2268 grams)
Ø 2.0" (50)
3.13
(80)
NPT Process
Connection
3.00
(76)
Ø 0.1875" (5) Cable
3.00
(76)
P
robe
Insertion
Length
7
xF: 2.36 (60)
7xJ: 4.96 (126)
Ø 0.50" (12) Rod
O
ptional Spacer
(P/N) 89-9114-001
Eclipse
®
with 7xF Probe
Flanged Connection
Eclipse
®
with 7xF Probe
NPT Threaded Connection
P
robe
I
nsertion
L
ength
P
rocess
Conn.
Ø
0.50" (12) Rod
Optional Spacer
(P/N) 89-9114-001
7xF: 2.24 (57)
7
xJ: 4.84 (123)
