57
57-600 Eclipse
®
Guided Wave Radar Transmitter
3.6.6 Physical – Coaxial Probes
inches (mm)
Eclipse
®
with 7XS/7xQ Probe
Flanged Connection
Eclipse
®
with 7XS Probe
Threaded Connection
D Dimension H Dimension
Probe Standard Enlarged NPT Flanged
7xA .875 (22) 1.75 (44) 2.32 (59) 2.91 (74)
7xD .875 (22) 1.75 (44) 8.55 (217) 10.91 (277)
7xP .875 (22) 1.75 (44) 4.18 (106) 6.54 (166)
7xQ 1.25 (32) — 7.10 (180) 9.52 (242)
7xR, 7xT .875 (22) 1.75 (44) 5.89 (150) 6.57 (167)
7xS .875 (22) — 7.10 (180) 9.52 (242)
COAXIAL PROBES
4.12
(105)
3.28
(83)
E
lect.
C
onn.
Qty. 2
Probe
Insertion
Length
Process
Conn.
45
H
10.08
(256)
4.00
(102)
D
4.12
(105)
3
.28
(
83)
E
lect.
C
onn.
Qty. 2
Probe
Insertion
Length
Process
Conn.
45
H
10.08
(256)
4.00
(102)
D
Eclipse
®
with 7xD Probe
Threaded Connection
Eclipse
®
with 7xD Probe
Flanged Connection
Eclipse
®
with 7xG Probe
max 240" (6.1 m)
4.12
(105)
3.28
(83)
4.00
(102)
Elect.
Conn.
Qty. 2
Probe
Insertion
Length
Process
Conn.
45
5.89
(150)
10.08
(256)
D
Eclipse
®
with 7xR or 7xT Probe
Threaded Connection
4.12
(105)
3.28
(83)
Elect.
Conn.
Qty. 2
Probe
Insertion
Length
Process
Conn.
45
6.57
(167)
10.08
(256)
4.00
(102)
D
Eclipse
®
with 7xR or 7xT Probe
Flanged Connection
2" cage: Ø 0.50 (13) rod
3" cage: Ø 19 (0.75) rod
4" cage: Ø 25 (1) rod
Probe
Insertion
Length
HT PEEK spacer
Ø 71 (2.80)
7.37
(187)
H
Mounting
Flange
3
.28
(
83)
4.12
(105)
10.08
(256)
1
02
(
4.00)
2
cable
entries
4
5°
P
robe
Insertion
Length
H
DD
3.28
(83)
4.12
(105)
1
0.08
(
256)
4.00
(
102)
2 cable
e
ntries
4
5°
Probe Insertion
L
ength
1
" BSP (G1)
Process Conn.
P
robe Insertion
Length
3
/4" NPT
P
rocess Conn.
