A LED Display: Operating Status
Red, yellow and green LEDs indicate the operating status. See also section "Troubleshooting".
When button is pushed, lift raises until button is released or upper end position is reached.
When button is pushed, lift lowers until button is released or lower end position is reached.
D LED Display: Number of Columns
Number of LEDs represents number of columns in a column unit. Flashing LED indicates next
free column number in an open column unit.
E Button: Open/Close Column Unit
Use this button to open a closed column unit or to close an open unit.
F LED Display: Column Unit
LED lighting up indicates that the column unit is closed. LED also lights up when operating
mode is changed (see below).
G LED Display: Channel Number
LED lighting up indicates current channel number.
H Button: Select Channel Number
Use this button to switch on to the next available channel. Occupied channels are skipped,
channel 10 is followed by channel 1 and so on.
I LED Display: Operating Mode
Current operating mode is indicated by LED.
J Button: Select Operating Mode
Use this button to switch on to the next mode. "Single" (one column), "Auto" (all columns of a
column unit) and "Group" (several columns) can be selected.
