Red
Yellow
Green
OFF OFF OFF
If no other LEDs are ON:
Emergency-stop actuated.
Enable emergency-stop button.
If other LEDs are ON: Radio
interference (e.g. Channel,
Mode…). Possible cause:
Devices in the vicinity trans-
mitting on the 433 MHz band
(such as garage door opener,
radio set…).
Wait until radio interference has
stopped.
OFF OFF Sensor error Contact service.
OFF Load nut failure detected. Contact service.
OFF
OFF
Lift is not yet referenced, when
a new column with new control
is being connected after final
assembly.
Lower lift with emergency-
down function.
Level difference between
columns too great.
OFF
OFF
Lift has contacted obstruction
or floor.
Raise lift until yellow LED goes
off.
and lift stops while lowering. Upper sensor maladjusted. Contact service.
OFF
OFF
Lift overloaded.
Rated load capacity exceeded.
Lowering still possible.
Sluggish operation. Possible
causes: Long standing under
load, insufficient lubrication…
Release button, try again.
Contact service if required.
Supply network too "weak".
Voltage drops when lift is
started, motor does not reach
working speed.
If error repeats, have network
inspected.
and lift stops while raising. Upper sensor maladjusted. Contact service.
OFF OFF Hardware error occurred.
Interrupt voltage for 5 sec. If
error persists, contact service.
OFF OFF
Voltage drop in supply network.
If error repeats, have network
inspected.
and lift stops during operation.
Error occurred (Watchdog).
Turn off main switch and turn
on again after approx. 5 sec. If
error repeats, contact service.
