DESCRIPTION
■ General construction
The transmission case, Clutch, Clutch housing, Engine and Front Axle Support are bolted together to
form a rigid unit .
The 4WD front axle is a center-pivot, reverse Eliot type. The front wheel drive mechanism is
incorporated as a part of the axle.
The front wheel drive power is taken off the rear transmission and transmitted to the differential in the
front axle where the power is divided into right and left and to the respective final cases.
In the final cases, the transmitted revolution is reduced by the level gears to drive the front wheel. The
4WD mechanism with level gears provides wider steering and greater durability.
The tractors are fitted with fuel efficient Turbo charged engines with 4 cylinders of 6110
designed by Daedong.
■ Clutch and Transmission
A single plate dry clutch (10.83"diameter) is used on these tractors. Tractors with IPTO
(Independent Power Take Off) are fitted with hydraulic Clutch Assy. The transmission Gear box has
12 forward & 12 reverse speeds of 6110. Presently, Mahindra Tractors are fitted with constant mesh
■ Brakes
Mahindra tractors are provided with independent disc brakes operated by two road travel. A foot
brake lever is fitted for parking.
■ Rear axle & Wheels
This is mounted on ball bearings and is enclosed in removable housings which are bolted to the
transmission case. The rim & Disc fitted with Rear tires are bolted to the outer flange of the Rear
.
■ Hydraulic system & Linkages.
Mahindra Tractors are fitted with Live (i.e. system is in operation even when clutch is disengaged.)
independent, System. Three point Linkages can be used for Category 2 types of implements.
12
