Mahindra 10 Series User Manual

► SHUTTLE SHIFT LEVER
This control allows shifting from forward to reverse &
reverse to forward. When stationary set the lever to N for neutral
① Push the lever away from the driver engages forward.
②
Pulling the lever towards the driver engages reverse
O
p
erate the shuttle shift onl
y
while seated on the tractor.
1.Press the clutch pedal down completely before operating the shuttle shift lever.
2.When changing from forward to reverse or back to forward again while in high
range make sure the tractor comes to a stop before changing direction. Failure to do
so is likely to result in damage to the mechanism and place the driver at risk of injury.
Important
②
Pulling
the
lever
towards
the
driver
engages
reverse
.
py
Do not use the shuttle shift lever to start the tractor for towing or traveling uphill, use
the clutch instead.
Always stop the tractor before getting off.
Caution
▶Main gear lever
This lever can be shifted by using the clutch, both
when the tractor is stationary or mobile.
It is located on the RHS of the driver seat.
▶ Sub gear lever(Linear shift lever)
Operate the sub gear lever using the clutch to select the
appropriate speed for different applications.
It is located on the LHS of driver seat.
Avoid damage!
Select the proper speed range and gear for the job.
• The machine maybe operated in any gear with engine speeds at 950-2600 rpm.
W
ithin th
ese
limit
s,
th
e
e
n
g
in
e
c
an
be
p
la
ced
u
n
de
r
v
ar
y
in
g
l
o
a
d
ope
rati
o
n
s.
Main gear lever
Sub gear lever(Linear shift lever)
42
W ese s, e e g e c be p ced u de v y g o d ope o s.
• Never overload engine by lugging machine at low idle speeds.
• Raise engine speed to match expected loads. If a slight increase in engine rpm
occurs simultaneously with the moving of the hand throttle lever forward, the
engine is not overloaded.
Important
