SPECIFICATIONS
Model: 6110 Gear Cab
ENGINE
CLUTCH
Four strokes, Indirect injection, water-cooled
Diesel Engine.
Model : 4B243TLW (Turbo)
No. of cylinders : 4
Displacement : 2,435 Liters
Bore : 87mm (3.3 in)
Stroke : 102.4mm
Compression Ratio : 22.1
Rated
p
ower
(
HP
)
: 59/2600 r
pm
Type : Diaphragm
Outer dia. X Inner dia. :
Ф275XФ180(10.83x7.09)
TRANSMISSION
Type : Synchro mesh
No. of gears : 12 forward,
12 reverse speeds
with high and low
selection lever with
Differential Lock
p() p
(Manufacturing rating)
Rated Speed : 2600 rpm
High idle rpm : 2,800±50 RPM
Low idle rpm : 1000 ±50
Fuel injection pump : BOSCH PFR TYPE.
Cylinder sleeve : -
Air Cleaner : Dry Filter element,
paper element filtering type.
Exhaust Muffler : Horizontal External type
Differential
Lock
STEERING : Hydraulic power
(Power steering)
POWER TAKE OFF
Rear mounted : 6 splines
Diameter : 1⅜ in.(35mm)
Standard PTO : ① 540
BRAKES
Foot operated independent with provision of
Exhaust
Muffler
:
Horizontal
External
type
Firing order : 1-3-4-2
Accelerator : Hand & Foot Accelerator
ELECTRICAL STARTING AND LIGHTING
Battery Capacity : 12 Volt 80AH
Starter : Solenoid Engaged.
Key Start with interlock,
Neutral switch
Al 12V 50A
Foot
operated
,
independent
with
provision
of
inter lock for simultaneous operation. A foot
brake is fitted for parking.
Disc Diameter :Φ184mm(Φ7.24in)
Number of lining :6 each side
Total brake thickness : 66.4㎜(2.614in.)
HYDRAULIC SYSTEM
Independent fully ”Live” hydraulic pump
Al
ternator :
12V
50A
Instrumentation : Water Temperature Gauge,
Tacho meter, Hour meter,
Electrical fuel level gauge.
Lighting: Head lamps, side indicators,
Rear parking brake
& indicator light
On dash board indicators
and separate reservoir. Position controls with
isolating & response control
Piston and cylinder Lift 1600 kgF
(at lower link top end)
Pump output :
Main : 16.0 cc/rev (41.6 ℓ/min)
Power Steering : 7.2 cc/rev (20.5 ℓ/min)
Delivery(91% efficiency) : liter(cu in)mm at
94
for battery charging, turn
signal, PTO signal, Engine
oil pressure, Preheat signal.
Delivery(91%
efficiency)
:
liter(cu
.
in)mm
at
2600rpm
3 point linkage : Category 2
