Mahindra 2810 Service Manual

-Lighting
4. STOP LIGHT SWITCH
OFF
**
2
21TB1*1
●●●
1
●
RG
(Red/
Green)
●
R
(Red)
●
2
RY
(Red/
Yellow)
RW
(Red/
White)
Color
code
Fig.10-15 Stop light switch
*1 :Terminals
**2: Switching positions
8mmTotal stroke
3 ±0.5mmStroke to ON
10~20A (DC12V)Capacity
-Flasher
●●
1**2
LRB2*1
OFF
WG
(White/
Green)
●
G
(Green)
●
2
GB
(Green/
Black)
Color
code
5.RELAY UNIT
Fig.10-16 Relay unit
*1 :Terminals
**2: Switching positions
6. FUSE
Fuses are installed in the main fuse box and one
for the headlights.Three fusible links are
installed to prevent the wiring from burning
due to a short circuit.
-Horn switch
Free**2
HB1*1
●●
Push
GW(Green/White)R(Red)Color code
*1 :Terminals
**2: Switching positions
Fig.10-17 Fuse box
10-8
