Mahindra 2810 - Rear Axle; Power Steering System; Hydraulic System

Service instructions
and remarks
Usable limitsStandard value
for reassembly
Nominal
dimensions
Part names and
inspection items
5.REAR AXLE (CHAPTER 7)
1) DISK BRAKE
3.4 ㎜3.4 ± 0.1 ㎜FRICTION
PLATE
THICKNESS
(WEAR AND
CARBONIZER )
2)SEPARATE PLATE
2.5 ㎜2.5 ± 0.09 ㎜Thickness
(wear and damage)
3) BRAKE ROD TURN BUCKLE
30 ～40 ㎜Pedal play at the
top
6. POWER STEERING SYSTEM( CHAPTER 8)
1) GEAR PUMP
CCW at 500 ～ 3500 rpm Direction of
revolution
Theoretical value/revolution
N=2500 rpm, P=150 ㎏f/㎠
Oil temperature : 50 ± 5 ℃
6.9 ㏄/rev (22.5 ℓ/min)Capacity
7.HYDRAULIC SYSTEM (CHAPTER 9)
1) PISTON AND CYLINDER
0-ring : Ø65㎜
Ø 75 ㎜cylinder and bore
11-6
