SECTION 5. EARTHING POINT
1
3
Fig.10-24
A
1) Front axle bracket (RH)
Earthed at upper upper tapped hole in the
axle bracket A.
Fig.10-26
3) Right surface of the frame comp.Where the
battery bracket is to be installed.
Fig.10-25
2) Contact surfaces of the axle bracket and engine
where they tightened together
10-11
