Mahindra 2810 Service Manual

8.Trailer socket
A hella’s 7-pin trailer socket is equipped as a standard equipment.Lamp on a trailer can be
operated through the socket.
Fig.10-23
5AVSS 0.85GYTurn signal (RH)5
4AVSS 0.85WLStop Light4
3AVSS 0.85GBTurn signal (LH)3
1AVSS 2.0BEarth1
7AVSS 0.85WGReserve light7
6AVSS 0.85YWRear Light (Number plate)6
2AVSS 0.85YSmall light(Tail light)2
Wire HousingSpecificationColorDescriptionSocket No.
Note:
Lamp on the trailer should be of the same size or smaller than those on the trailer.
10-10

Mahindra 2810 Specifications

General

Engine Power	28 HP
Engine Cylinders	3
Drive	2WD
Engine Type	Diesel
Transmission	8 Forward + 2 Reverse
Steering Type	Manual
Clutch Type	Single
