Service instructions
and remarks
Usable limitsStandard value
for reassembly
Nominal
dimensions
Part names and
inspection items
2) REAR TRANSMISSION
(1) DRIVE PINION & RING GEAR
0.1 ～ 0.2 ㎜
0.08 - 0.11 ㎏·m
0.5 ㎜Backlash
Starting torque
Available shims on drive pinion
metal(support)
Shim A : 0.1 ㎜
Shim B : 0.2 ㎜
Available shims on dif-case
Shim A : 0.1 ㎜
Shim B : 0.2 ㎜
Adjustment of relative positioning
between drive pinion and ring gear
Drive pinion and
ring gear support
shimming
(2) DIFFERENTIAL
Pinion thrust collar or
gear
0.5 ㎜0.1 ～ 0.2 ㎜Backlash between
dif-pinion and dif-
side gear
11-4
