CAM SHAFT,PUSH ROD,TIMING COVER SUB-ASSEMBLY
19 High Idle seting Hex Nut (M8 - 8) 18 to 22 Nm
20 Hex bolt for Timing cover (M 8 x 30 - 8.8) 25 to 30Nm
21 Hex bolt for P.T.O. shaft (M 10 x 45 - 8.8) 48 to 52 Nm
PISTON,CON. ROD SUB -ASSEMBLY
22 Con Rod bolt (M10 x 48 - 12.9) 60 TO 65 Nm
23 Stud for water inlet flange (M8 x 22 ) 12 to 15 Nm.
24 Hex bolt for closed flang of water inlet (M8 x 12-8.8) 20 to 25 Nm
CYLINDER HEAD SUB-ASSEMBLY
25 Injector flange stud (M 8 x 40 - 5.6) 10 to 12 Nm
26 Exh. And Air Intake manifold mtg. stud (M10X42X1.5) 45 to 50 Nm
27 Exh.manifold mtg bolt (M 8 x 25) 20 to 25 Nm
28 Breather pipe mtg stud (M 6 x 30 - 5.8) 10 to 12 Nm
29 Hex nut for Adjustment screw of rocker (M8) 18 to 22Nm
30 Hex bolt for Rocker shaft locking (M6 x 16-8.80 10 to 12 Nm
31 Hex Nut for cy.head (M12) 127 to 147 Nm
32 Rocker cover hex bolt (M8 x 50-8.8) 25 to 30 Nm
33 Rocker cover hex bolt (M8 x 75-8.8) 25 to 30 Nm
34 Hex nut for breather pipe (M 6 – 8.8) 10 to 12 Nm
35 Water Temperature Sensor 25 to30 Nm
36 Oil Pressure Switch 15 to 20 Nm
TORQUE CHART FOR YUVRAJ 215 - FMW100 ENGINE
SR. DESCRIPTION & BOLT/NUT/STUD USED TORQUE-Nm
NO.
